ADT-CNC9960 CNC Milling Controller manufacturer
Function:
- Pulse frequency up to 1M;
- 56 input and 48 output ports;
- 2-channel 0-10v analog output Control;
- a set of PWM analog control port;
- 256M built-in electronic disk, support 8G storage space expansion.
Feature:
- 6 axis movement, 6 axis interpolation linkage movement;
- 6 stepper / servo motor control;
- Independent servo spindle;
- Speed prospect processing, control the speed transition smooth;
- Support straight line magazine, disc magazine, cylinder tool change and magazine features customize;
- System self diagnose and parameters backup, recovery function;
- Support USB, Ethernet, serial communication, U disk, SD card operation;
- Support MPG running G code;
- G code track preview, real-time tracking and syntax check function.
Application:
-
- Metal parts processing (car / boat, electrical hardware processing industry);
- Glass products (mobile phones, televisions, computers, electrical switches and other glass panel processing);
- Wooden furniture garden art (furniture, handicrafts, wooden temple sculpture landscaping);
- Flexible processing line (milling, grinding, polishing and other processes producing line factory).
-
CNC System Function
- Self-diagnosis
Diagnose CPU, memory, LCD, I/O interface, parameter state, coordinates and processing program comprehensively every time the system is started or reset; diagnose power supply, principal axis, limit and I/O ports in real-time during operating. - Compensation
Automatic reverse clearance compensation
Automatic tool length compensation
Automatic tool radius compensation
Automatic tool radius biasing and automatic tool tip transition - Abundant instruction system
Scaling instruction
Mirror processing instruction
Tool biasing instructions
Program cycle, program skip, program shift, program transfer, different end processing modes, macro definition and program management instructions
Fixed-point instructions: starting point, setting point, etc.
Linear, arc and spiral interpolation instructions
Six workpiece coordinate systems, nine extension coordinate systems and one reference point - Full English menu operation & full screen edit
4640/4620 CNC control system uses cascading menu structure and full Chinese operation to ensure simple operation and visibility. - Abundant error-correction functions
Point out the nature and correct the errors in operation. - Program exchange between CNC system and PC
Perform CAD/CAM/CAPP auxiliary programming with abundant software in PC, and then transmit CNC program to the system through communication interface (USB disk, RS232 interface), or transmit the programs from the system to PC. - CNC system operating condition
Operating voltage
24V DC (with filter)
Operating temperature
0°C— 45°C
Optimum operating temperature
5°C— 40°C
Operating humidity
10%——90%(no condensing)
Optimum operating humidity
20%——85%
Storage temperature
0°C—50°C
Storage humidity
10%——90%
Operating environment
No excessive dust, acid, alkali, corrosive and explosive gases, no strong electromagnetic interference
